丰富的应用选件可选,便于进行调试和增强分析

使用应用选件来扩展示波器的分析功能,包括基于协议的触发和解码、依据最常用接口标准的自动化一致性测试、一般分析(比如抖动或电源)以及矢量信号分析。

触发和解码包
产品名称
Min. bandwidth
Description
Min. bandwidth
50 / 50 / 500 MHz
Description
Trigger & decoding of ARINC 429/ MIL-1553 / SpaceWire data & communication buses.
Min. bandwidth
600 MHz
Description
Triggering and decoding of 100BASE-T1/BroadR-Reach® and 1000BASE-T1 Automotive Ethernet
Min. bandwidth
50 MHz
Description
T&D package for automotive protocols such as CAN, CAN-FD, CAN-XL, LIN, FlexRay, SENT, CXPI
Min. bandwidth
600 MHz
Description
8b10b, Manchester and NRZ
Min. bandwidth
600 MHz
Description
Decoding software 10Base-T, 100Base-Tx and MDIO
最小带宽
600 MHz
描述
串行触发和解码:I2C/SPI/RS-232/UART/I2S/LJ/RJ/TDM/Manchester/NRZ
Min. bandwidth
4 GHz
Description
D-PHY ( DSI, CSI-2), M-PHY / UniPro
Min. bandwidth
1 GHz
Description
MIPI RFFE
最小带宽
6 GHz
描述
8b 10b, PCI Express 1.1/2.0/3.0
Min. bandwidth
2 GHz
Description
USB 1.1 / 2.0 / 3.2 Gen1/2 / HSIC/SSIC / Power Delivery (PD)
串行触发和解码
产品名称
最小带宽
描述
最小带宽
-
描述
针对串行协议解码的总线测量
最小带宽
600 MHz
描述
100BASE-T1/BroadR-Reach® 和 1000BASE-T1 车载以太网触发和解码
最小带宽
600 MHz
描述
针对 8b10b 总线的通用解码
最小带宽
50 MHz
描述
针对 ARINC 429 总线的触发和解码
最小带宽
50 MHz
描述
针对 CAN 和 LIN 接口的触发和解码
最小带宽
50 MHz
描述
针对 CAN-FD 的触发和解码
最小带宽
50 MHz
描述
根据 SAE J3076 标准对时钟扩展外围接口 (CXPI) 总线进行触发和解码
最小带宽
600 MHz
描述
10BASE-T 和 100BASE-TX 以太网解码
最小带宽
50 MHz
描述
针对 FlexRay™ 总线的触发和解码
最小带宽
50 MHz
描述
针对 I²C 和 2 线、3 线或 4 线 SPI 总线的触发和解码
最小带宽
50 MHz
描述
针对 I²S 总线的触发和解码
最小带宽
200 MHz
描述
触发和解码任何使用曼彻斯特编码和不归零编码的串行协议,例如 Profibus PA、DALI、MVB 和多种专有协议
最小带宽
200 MHz
描述
针对 MDIO 的触发和解码
最小带宽
50 MHz
描述
针对 MIL-STD-1553 总线的触发和解码
最小带宽
4 GHz
描述
基于 MIPI D-PHY 的协议 DSI 与 CSI-2 触发和解码
最小带宽
4 GHz
描述
MIPI M-PHY 物理层与 UniPro 协议层触发和解码
最小带宽
1 GHz
描述
MIPI RFFE 协议触发和解码
最小带宽
6 GHz
描述
触发和解码 PCI Express Gen 1.1、2.0 和 3.0 信号
最小带宽
50 MHz
描述
针对基于 UART 的协议及 RS-232、RS-422、RS-485 总线的触发和解码
最小带宽
50 MHz
描述
针对快速通道以及短和增强型串行消息的触发和解码。符合 SENT SAE J2716 v2010 和更低兼容标准。
最小带宽
500 MHz
描述
针对 SpaceWire 数据和通信总线的触发和解码。
最小带宽
2 GHz
描述
针对所有 USB 1.x/2.0 数据率的触发和解码:高速 (480 Mbit/s)、全速 (12 Mbit/s) 和低速 (1.5 Mbit/s)
最小带宽
13 GHz
描述
触发和解码 USB 3.1 Gen 1 和 Gen 2 信号
最小带宽
1 GHz
描述
USB Power Delivery (USB-PD) 信号触发和解码
最小带宽
2 GHz
描述
USB-SSIC 信号触发和解码
一致性测试
产品名称
最小带宽
描述
最小带宽
600 MHz
描述
按照 IEEE 测试规范针对 10/100/1000BASE-T 以太网接口的自动化一致性测试解决方案
最小带宽
600 MHz
描述
按照 IEEE 测试规范针对 10/100/1000BASE-T 以太网接口的自动化一致性测试解决方案
最小带宽
1 GHz
描述
按照 IEEE 测试规范针对 2.5G/5GBASE-T 以太网接口的自动化一致性测试解决方案
最小带宽
3 GHz
描述
按照 IEEE 测试规范针对 10GBASE-T 以太网接口的自动化一致性测试解决方案。
最小带宽
4 GHz
最小带宽
600 MHz
描述
按照 IEEE 802.3cg 规范针对 10BASE-T1S 和 10BASE-T1L 以太网的自动化一致性测试解决方案
最小带宽
600 MHz
描述
按照 OpenSIG 一致性测试规范针对 100BASE-T1/BroadR-Reach® 以太网的自动化一致性测试解决方案
最小带宽
2 GHz
描述
符合 IEEE 802.3bp 规范的 1000BASE-T1 以太网一致性测试解决方案
最小带宽
2 GHz
描述
DDR3 和 DDR4 自动化一致性测试解决方案
最小带宽
1 GHz
描述
按照 JEDEC 规范 JESD84-B51 第 5.1 版针对 eMMC 接口的自动化一致性测试解决方案,涵盖 HS200 和 HS400 总线速度模式
最小带宽
4 GHz
描述
按照 HDMI 论坛 1.4b/2.1 (TMDS) 测试规范针对 HDMI 接口的自动化一致性测试解决方案
最小带宽
4 MHz
描述
按照 MIPI 和 UNH-IOL 测试规范针对 R&S®MIPI D-PHY 的自动化一致性测试解决方案
最小带宽
4 GHz
描述
按照 MIPI 和 UNH-IOL 测试规范针对 R&S®MIPI D-PHY 的自动化一致性测试解决方案
最小带宽
6 GHz
描述
按照 PCI-SIG 一致性测试规范针对 PCI Express 接口(系统和插卡)的自动化一致性测试解决方案
最小带宽
2 GHz
最小带宽
-
描述
100BASE-T、100BASE-T1 和 1000BASE-T1 全自动化以太网一致性测试
最小带宽
13 GHz
描述
针对 DisplayPort 1.4a 和嵌入式 DisplayPort 1.4b/1.5 的自动化一致性测试解决方案(涵盖比特率模式 RBR、HBR、HBR2、HBR3)
一般分析
产品名称
描述
描述
使用可配置的 8/16 Gbps HW-CDR 对捕获波形进行高级眼图分析
描述
扩展 R&S®Scope Rider 手持式示波器的触发功能。支持其他触发类型,例如码型、状态、欠幅、斜率、窗口、data2clock、串行码型、超时、间隔、TV/视频
描述
使用 R&S®RTO 示波器对嵌入式时钟执行实时时钟数据恢复
描述
实时去嵌,快速获取结果
描述
适合 R&S®Scope Rider 手持式示波器的频率计
描述
频率响应分析选件使用示波器的内置波形发生器生成 10 Hz 至 25 MHz 的激励信号。
描述
使用 R&S®Scope Rider 手持式示波器,显示最多 64 次谐波
描述
将罗德与施瓦茨示波器的垂直分辨率最高增加到 16 位
描述
捕获和分析长时间内的脉冲和突发信号
描述
借助高达 16 Gbps 基于硬件的时钟数据恢复 (CDR) 分析高速串行信号
描述
周期间抖动或时间间隔误差 (TIE) 等抖动测量;支持轨迹显示
描述
分离随机抖动/噪声、数据相关抖动/噪声或周期性抖动/噪声等独立的抖动和噪声成分;显示阶跃响应、直方图、综合眼图、频谱和误码率浴盆曲线
描述
提供自动化测量和向导支持,可分析开关电源和线性电源的特性
描述
增强罗德与施瓦茨示波器的多通道频谱分析功能,包括瀑布图
描述
触发用户自定义区域。区域可应用于通道、数学运算和 FFT 信号
矢量信号分析
产品名称
描述
描述
将调制信号转换为 I/Q 数据以供进一步处理
描述
R&S®VSE 矢量信号分析软件将罗德与施瓦茨强大的信号分析体验和功能应用于示波器,提供了广泛的分析选件,可用于排查问题并优化设计
Description
Integrated setup control for external R&S®FExx frontends
分析/远程控制软件
产品名称
描述
描述
适用于罗德与施瓦茨示波器的 R&S®InstrumentView 远程分析软件:将示波器上的波形下载到计算机,然后使用此软件进行详尽分析。
描述
R&S®CDS 校园仪表板软件可以简化多工作台实验室的学生教学工作。
描述
支持使用 R&S®Scope Rider 的集成式 WLAN 模块,轻松实现对 R&S®Scope Rider 的远程控制。
描述
通过任何笔记本电脑或平板电脑的 Web 浏览器控制 R&S®Scope Rider 触控界面和按键区。(需要 R&S®RTH-K200 或 R&S®RTH-K200US 选件)。
