R&S®Cloud4Testing: Pulse analysis application package

涵盖所有相关脉冲参数的云测试解决方案

R&S®Cloud4Testing: Pulse analysis application package
打开灯箱
R&S®Cloud4Testing:脉冲分析应用包,屏幕截图

主要特点

  • 测量深度脉冲分析所需的所有相关参数
  • 生成有关多个脉冲的趋势分析
  • 提供灵活的订阅模式

应对脉冲分析挑战,需要精益解决方案

基于云的软件可快速轻松地测量所有相关的脉冲参数

此脉冲分析应用包适用于 R&S®Cloud4Testing,可用于 R&S®VSE-K6 选件,并专用于测量所有相关参数(例如脉宽、脉冲周期、脉冲上升和下降时间、脉冲内功率下降以及脉间调相),并且能够生成有关多个脉冲的趋势分析。用户可以选择在屏幕上同时显示多个结果。R&S®VSE 可在数秒内提供雷达系统全图。

特性和优点

脉冲参数

脉宽、脉冲重复率、脉冲重复间隔、占空比、上升/下降时间、稳定时间
脉冲统计数据:标准差、平均值、最大值、最小值
脉冲表

打开灯箱

频率、功率、相位和幅度

频率:载波频率、脉间频差、调频斜率、频率偏差、频率误差
功率:峰值功率、平均功率、峰均功率、脉间功率
相位:载波相位、脉间相位差、相位偏差、相位误差
幅度:顶降、纹波、过冲宽度

进一步测量

脉内点测量:频率、幅度、相位与脉冲,以及所有参数的趋势和直方图
用户自定义的测量参数

可用型號

可用型號
型号
有效期

Pulse Analysis Free Trial

有效期
30 天

Pulse Analysis

有效期
12 个月
