R&S®Cloud4Testing: 5G application package

适用于 5G NR 设备开发的云测试解决方案

R&S®Cloud4Testing: 5G application package
打开灯箱
R&S®Cloud4Testing:5G 应用包,屏幕截图

主要特点

  • 根据 3GPP 5G NR 标准分析 5G NR 设备的射频性能
  • 即时针对上行链路和下行链路 I/Q 文件执行测量
  • 提供灵活的订阅模式

应对 5G 挑战,需要精益解决方案

基于云的软件可快速轻松地根据 3GPP 标准进行分析

此 5G 应用包适用于 R&S®Cloud4Testing,可用于 R&S®VSE-K144 测量应用,并涵盖上行链路和下行链路中的 3GPP 5G NR 带内测量。所有信号子帧都将进行分析,并提供广泛的测量结果,包括不同通道和信号的误差矢量幅度 (EVM)、频率和功率。

特性和优点

深度 5G 物理层信号分析

R&S®VSE-K144 测量应用支持从 5 MHz 到 400 MHz 的所有指定 5G 信号带宽,其中包含多个参数集、带宽分片以及从 QPSK 到 256QAM 的不同调制格式。

打开灯箱

支持多种测量

  • 误差矢量幅度 (EVM)
  • 星座图
  • I/Q 偏置
  • 增益不平衡
  • 正交误差
  • 中心频率误差(符号时钟误差)
  • 分配总结列表
  • 通道解码器结果
  • 多次测量平均值
  • R&S®Cloud4Testing 5G 应用包还包含用于使用 SnP 文件进行频率响应校正的 R&S®VSE-K544 选件。

可用型號

可用型號
型号
有效期

5G Analysis Free Trial

有效期
30 天

5G Analysis

有效期
12 个月
