主要特点
- 系统频率范围:10 MHz 至 110 GHz
- 动态范围高达 130 dB(典型值)
- 两个测试端口,1.0 mm 阳性
- R&S®ZVA67 基本单元可用作独立装置
R&S®ZVA110 的频率范围介于 10 MHz 至 110 GHz。它以 R&S®ZVA67 四端口矢量网络分析仪为基础,并包含所有系统组件以无缝进行连续扫描(03 和 13 型号)
亮点:
系统可以使用包含的 R&S®ZVA-Z110E 变频器(无双工器)重新进行配置,以设置组合解决方案。因此,分析仪可结合 WR10 波导连接器法兰,并在 75 GHz 至 110 GHz 频率范围内提供一流性能。
R&S®ZVA110 可轻松进行重新配置以组成组合解决方案,将 R&S®ZVA67 基本单元和 R&S®ZCxx 与 R&S®ZVA-Zxx 毫米波变频器结合在一起(需要使用附加电缆和适配器)。
R&S®ZVA110 *.03 和 *.13 型号(大功率型号)包含所有射频和控制电缆。但是,晶圆上安装等部分应用需要使用用户提供的长度不一的射频电缆。为了节省不必要的费用,R&S®ZVA110 *.05 和 *.15 型号不含射频电缆。
不使用频率扩展设备而操作 R&S®ZVA67 的时候,基本单元的性能不受限制:至多可提供四个内部信号源以用于混频器、变频器/接收机和收发模块测量,并具备一流的灵敏度、动态范围和频率范围。信号源相位控制支持真实差分和多路径传播测试。所有 R&S®ZVA67 选件均可安装,并可以使用 R&S®ZVAX-TRM67 扩展单元进一步扩展功能。
订单号码 1164.0209.69
直接发生器/接收机接入,针对四端口 R&S®ZVA67;
订单号码 1164.0209.08
直接发生器/接收机接入,针对双端口 R&S®ZVA8;
订单号码 1164.0209.10
直接发生器/接收机接入,针对四端口 R&S®ZVA8;
订单号码 1305.7077.02
发生器步进衰减器,端口 1
50 dB(按 10 dB 步进),机械,67 GHz
订单号码 1305.7083.02
发生器步进衰减器,端口 2
50 dB(按 10 dB 步进),机械,67 GHz
订单号码 1305.7090.02
发生器步进衰减器,端口 3
50 dB(按 10 dB 步进),机械,67 GHz
订单号码 1305.7102.02
发生器步进衰减器,端口 4
50 dB(按 10 dB 步进),机械,67 GHz
订单号码 1164.0009.02
发生器步进衰减器,端口 1
70 dB(按 10 dB 步进),机械,8 GHz
订单号码 1164.0015.02
发生器步进衰减器,端口 2
70 dB(按 10 dB 步进),机械,8 GHz
订单号码 1164.0021.02
发生器步进衰减器,端口 3
70 dB(按 10 dB 步进),机械,8 GHz
订单号码 1164.0038.02
发生器步进衰减器,端口 4
70 dB(按 10 dB 步进),机械,8 GHz
订单号码 1305.7119.02
接收机步进衰减器,端口 1
35 dB(按 5 dB 步进),机械,67 GHz
订单号码 1305.7125.02
接收机步进衰减器,端口 2
35 dB(按 5 dB 步进),机械,67 GHz
订单号码 1305.7131.02
接收机步进衰减器,端口 3
35 dB(按 5 dB 步进),机械,67 GHz
订单号码 1305.7148.02
接收机步进衰减器,端口 4
35 dB(按 5 dB 步进),机械,67 GHz
订单号码 1164.0044.02
接收机步进衰减器,端口 1
35 dB(按 5 dB 步进),机械,8 GHz
订单号码 1164.0050.02
接收机步进衰减器,端口 2
35 dB(按 5 dB 步进),机械,8 GHz
订单号码 1164.0067.02
接收机步进衰减器,端口 3
35 dB(按 5 dB 步进),机械,8 GHz
订单号码 1164.0073.02
接收机步进衰减器,端口 4
35 dB(按 5 dB 步进),机械,8 GHz
订单号码 1164.1757.02
恒温晶体振荡器 (OCXO)
订单号码 1305.6306.02
通用接口
订单号码 1312.7856.02
升级到 Windows10,适用于 R&S®ZVA 和 R&S®ZVT;
CPU FMR11 已安装,包括 升级到固态硬盘(可升级选件,可由当地的罗德与施瓦茨服务团队安装。需另付安装费用)
订单号码 1312.7856.03
升级到 Windows10,适用于配备 FMR6 的 R&S®ZVA
含从 CPU FMR6 升级到 FMR11,包括 升级到固态硬盘(可升级选件,仅可由罗德与施瓦茨梅明根生产工厂安装。需另付安装费用)
订单号码 1312.7856.04
升级到 Windows10,适用于配备 FMR6 的 R&S®ZVT
含从 CPU FMR6 升级到 FMR11,包括 升级到固态硬盘(可升级选件,仅可由罗德与施瓦茨梅明根生产工厂安装。需另付安装费用)
订单号码 1312.7856.05
升级到 Windows10,适用于配备 FMR7 的 R&S®ZVA 和 R&S®ZVT
含从 CPU FMR7 升级到 FMR11,包括 升级到固态硬盘(可升级选件,仅可由罗德与施瓦茨梅明根生产工厂安装。需另付安装费用)
订单号码 1312.7856.06
升级到 Windows10,适用于配备 FMR9 的 R&S®ZVA 和 R&S®ZVT
含从 CPU FMR9 升级到 FMR11,包括 升级到固态硬盘(可升级选件,可由当地的罗德与施瓦茨服务团队安装。需另付安装费用)
订单号码 1312.7733.02
CPU FMR7 升级到 FMR11,适用于 R&S®ZVA、ZVT
包括升级到 Windows Embedded 标准 7
订单号码 1312.7733.03
CPU FMR6 升级到 FMR11,适用于 R&S®ZVA;
包括升级到 Windows Embedded 标准 7
订单号码 1312.7733.04
CPU FMR6 升级到 FMR11,适用于 R&S®ZVT;
包括升级到 Windows Embedded 标准 7
订单号码 1312.7733.06
CPU FMR9 升级到 FMR11,适用于 R&S®ZVA、ZVT
包括升级到 Windows Embedded 标准 7
订单号码 1305.7419.02
FMR7/x 升级至 FMR9/6
所有 R&S®ZVA 和 R&S®ZVT;
订单号码 1305.7419.03
FMR6/5 升级至 FMR9/6,适用于 R&S®ZVA;
所有 R&S®ZVA,包括 R&S®ZVA67、R&S®ZVA110;
订单号码 1164.0715.03
可移动闪存盘,4 GB
用于 R&S®ZVA、R&S®ZVB,带 FMR7/3 和 FMR7/6 控制单元
订单号码 1164.0715.04
可移动硬盘,500 GB
用于 R&S®ZVA、R&S®ZVB,FMR7、FMR9 和 FMR11 仅工厂安装(包括固件)
订单号码 1164.1111.03
附加可移动闪存盘,4 GB
用于 R&S®ZVA、R&S®ZVB,带 FMR7/3 和 FMR7/6 控制单元,需要选件 ZVAB-B18 (1164.0715.03)
订单号码 1164.1111.04
附加可移动硬盘,500 GB
用于 R&S®ZVA、R&S®ZVB,带 FMR7/3 和 FMR7/6 控制单元,需要选件 ZVAB-B18 (1164.0715.04)
订单号码 1164.1111.05
附加可移动硬盘,500 GB
用于 R&S®ZVA、R&S®ZVB,带 FMR9 控制单元,需要选件 ZVAB-B18 (1164.0715.04)
订单号码 1164.1111.06
附加可移动硬盘,500 GB,包括固件
用于 R&S®ZVA,带控制器 FMR11 固件,针对内含的 R&S®ZVA/ZVB,需要选件 R&S®ZVAB-B18 (1164.0715.04)
订单号码 1164.1111.07
附加可移动闪存盘,4 GB
订单号码 1096.3302.00
19" 机架适配器
用于将一个 19" 外壳(6 RU 高)安装在标准 19" 机架中
订单号码 1164.1492.02
脉冲测量
25 ms 记录时间,(针对双端口型号)
订单号码 1164.1492.03
脉冲测量
25 ms 记录时间,(针对四端口型号)
订单号码 1307.6026.02
外部衰减器控制
订单号码 1305.6541.02
适用于 R&S®ZVA-K9 的电缆组件;
用于使用 R&S®ZVA8 的内耦合器生成双音信号
订单号码 1322.6500.24
扩展单元
订单号码 1312.7710.28
升级到 4 个信号源,适用于 R&S®ZVA24;
现有的双信号源 R&S®ZVA24 四端口型号可升级到 4 个信号源
订单号码 1305.6541.03
适用于 R&S®ZVA-K9 的电缆组件;
用于使用 R&S®ZVA24 和 R&S®ZVA40 的内耦合器生成双音信号
订单号码 1322.6500.40
扩展单元
订单号码 1312.7710.48
升级到 4 个信号源,适用于 R&S®ZVA40;
现有的双信号源 R&S®ZVA40 四端口型号可升级到 4 个信号源
订单号码 1322.6500.50
扩展单元
订单号码 1305.6541.04
适用于 R&S®ZVA-K9 的电缆组件;
用于使用 R&S®ZVA50 和 R&S®ZVA67 的内耦合器生成双音信号
订单号码 1322.6500.67
扩展单元
订单号码 1164.1657.02
时域 (TDR)
(用于 R&S®ZVA、R&S®ZVB、R&S®ZVT);
订单号码 1164.1828.02
噪声系数测量
双端口设备上的噪声系数测量(针对 R&S®ZVA 和 R&S®ZVT,包含 R&S®ZVA-K17 选件(5 MHz 带宽)),(软件许可)
订单号码 1164.1863.02
变频
订单号码 1311.3134.02
矢量校正混频器测量
需要 R&S®ZVA-B16、R&S®ZVA-K4,推荐 R&S®ZVA 四端口装置
订单号码 1164.1540.02
真实差分测量
需要第二个内部源
订单号码 1164.1511.02
脉冲测量
3 ms 记录时间
订单号码 1307.7022.02
变频器控制
(用于 R&S®ZVA24/40/50/67);
订单号码 1311.3128.02
嵌入式本振混频器延时测量
(需要 R&S®ZVA-B16)(需要 R&S®ZVA-K4、R&S®ZVA 四端口装置)
订单号码 1164.1805.02
远距离群延时测量
需要 R&S®ZVA-B16、R&S®ZVA-K9、R&S®ZVA-K4 和 VISA I/O BIB
订单号码 1164.1070.02
5 MHz 接收机带宽
订单号码 1164.1892.02
双内部脉冲发生器
(用于 R&S®ZVA 和 R&S®ZVT);
订单号码 1317.8938.02
变频噪声系数测量
变频被测设备的噪声系数测量, 适用于 R&S®ZVA 和 R&S®ZVT,需要 R&S®ZVA-K4 和 R&S®ZVA-K30(软件许可)
订单号码 1328.8534.10
力矩扳手,0.45 Nm
用于 1.0 mm 连接器,6 mm 开口宽度
订单号码 1328.8534.11
力矩扳手,0.23 Nm 连接力矩
用于 1.0 mm 连接器,6 mm 开口宽度
订单号码 1328.8534.12
力矩扳手,0.34 Nm
用于 1.0 mm 连接器,6 mm 开口宽度
订单号码 1328.8534.19
力矩扳手,0.9 Nm
订单号码 1328.8534.35
力矩扳手,0.9 Nm
Torque Wrench for 3.5/2.92/2.4/1.85 mm connectors with 8 mm width across flats, 0.9 Nm coupling torque
订单号码 1328.8534.71
力矩扳手,1.5 Nm
用于 N 型连接器,20 mm 开口宽度
订单号码 0272.4010.50
衰减器
0 Hz 至 12.4 GHz,阳性/阴性 3 dB,2 W
订单号码 0272.4110.50
衰减器
0 Hz 至 12.4 GHz,阳性/阴性 6 dB,2 W
订单号码 0272.4210.50
衰减器
0 Hz 至 12.4 GHz,阳性/阴性 10 dB,1 W
订单号码 0272.4310.50
衰减器
0 Hz 至 12.4 GHz,阳性/阴性 20 dB,1 W
订单号码 1073.8695.03
大功率衰减器,50 W
0 Hz 至 2 GHz
订单号码 1073.8695.06
大功率衰减器,50 W
0 Hz 至 2 GHz
订单号码 1073.8695.10
大功率衰减器,50 W
0 Hz 至 2 GHz
订单号码 1073.8695.20
大功率衰减器,50 W
0 Hz 至 2 GHz
订单号码 1073.8695.30
大功率衰减器,50 W
0 Hz 至 2 GHz
订单号码 1073.8495.03
大功率衰减器,100 W
0 Hz 至 2 GHz
订单号码 1073.8495.06
大功率衰减器,100 W
0 Hz 至 2 GHz
订单号码 1073.8495.10
大功率衰减器,100 W
0 Hz 至 2 GHz
订单号码 1073.8495.20
大功率衰减器,100 W
0 Hz 至 2 GHz
订单号码 1073.8495.30
大功率衰减器,100 W
0 Hz 至 2 GHz
订单号码 1035.1700.52
大功率衰减器,50 W
0 Hz 至 6 GHz,20 dB
订单号码 1303.7840.02
50 Ω 宽带限幅器
订单号码 0272.4510.50
精密终端,75 Ω
1 W,DC 至 3 GHz,N 型阳性
订单号码 0272.4910.50
终端,50 Ω
1 W,DC 至 4 GHz,N 型阳性
订单号码 0200.0019.55
特高频终端,50 Ω
0 Hz 至 2 GHz,100 W,N 型阴性
订单号码 0289.8966.00
引线终端,50 Ω
0.5 W,DC 至 1 GHz,BNC(阳性/阴性)
订单号码 0844.9352.02
引线终端,50 Ω
2 W,DC 至 500 MHz,BNC(阳性/阴性)
订单号码 0358.5414.02
匹配件,75 Ω,L 型
双向,0 Hz 至 2.7 GHz,N 型阴性连接器/N 型阳性连接器,负载容量 2 W,L 型
订单号码 0358.5714.02
匹配件,75 Ω,串联电阻器 25 Ω
0 Hz 至 2.7 GHz
订单号码 0358.5714.03
匹配件 50/75 Ω,串联电阻器 25 Ω
0 Hz 至 3.3 GHz
订单号码 0800.6612.52
功分器,2 x 50 Ω
0 Hz 至 2.7 GHz
订单号码 1307.0886.02
双向 Wilkinson 功率分配器
4 GHz 至 27 GHz
订单号码 3626.4937.02
脉冲星四路功率分配器,5 GHz 至 27 GHz
5 GHz 至 27 GHz
订单号码 1314.5373.00
SMA 适配器,阳性/阳性,角形
0 Hz 至 18 GHz
订单号码 1314.5380.00
SMA 适配器,阳性/阴性,角形
0 Hz 至 18 GHz
订单号码 1324.5001.02
波导同轴适配器,WR15 转 1.85 mm(阳性)
50 GHz 至 75 GHz
订单号码 3592.6727.02
波导同轴适配器,WR15 转 1 mm(阳性)
订单号码 3592.6733.02
波导同轴适配器,WR15 转 1 mm(阴性)
订单号码 3626.1044.02
波导同轴适配器,WR15 转 1 mm(阴性)
50 GHz 至 75 GHz
订单号码 3626.1044.03
波导同轴适配器,WR15 转 1 mm(阳性)
50 GHz 至 75 GHz
订单号码 3626.1050.02
波导同轴适配器,WR12 转 1 mm(阴性)
60 GHz 至 90 GHz
订单号码 3626.1050.03
波导同轴适配器,WR12 转 1 mm(阳性)
60 GHz 至 90 GHz
订单号码 3626.1067.02
波导同轴适配器,WR10 转 1 mm(阴性)
75 GHz 至 110 GHz
订单号码 3626.1067.03
波导同轴适配器,WR10 转 1 mm(阳性)
75 GHz 至 110 GHz
