PCIe 1.1/2.0 示波器软件选件

触发和解码

SW_RTx-K72
打开灯箱
SW_RTx-K72

主要特点

  • 全面支持 PCI Express 1.1/2.0,数据率最高为 5 Gbit/s 且链路大小最高增加 4 倍
  • 预先定义或用户自选的比特率
  • 对交换层数据包 (TLP)、数据层数据包 (DLLP)、顺序集和错误等协议细节进行可靠的触发
  • 可选解码层:比特位,加扰或解扰 8b10b,或最终协议层
  • 可单独配置的时钟数据恢复,以便进行解码
  • R&S oscilloscopes | Engineered for multi-domain challenges

示波器软件选件

R&S®RTO 示波器支持对 PCI Express Gen 1.1 和 2.0 信号的触发和解码。解码设置仅需数秒。用户能够以颜色编码的报文形式和/或在解码表中查看结果,并作详细分析。通过硬件加速触发,可以有效地识别错误。用户可以针对交换层数据包 (TLP)、数据层数据包 (DLLP)、顺序集和错误条件进行触发。

特性和优点

在数秒内完成总线设置

通过应用面板,只需几个步骤即可配置任意特定协议。选择需要解码的总线和连接的通道,并设置正确的电平之后,就会自动开始解码。

示波器——串行触发和解码
打开灯箱

使用 R&S®RTO2000 轻松配置 PCIe 解码

以颜色编码的总线形式显示

用户可以将信号与颜色编码数据叠加,以便分析解码总线帧。地址和数据内容可以十六进制、二进制或 ASCII 格式显示。用户始终可以通过灵活的屏幕设置获得理想的浏览效果。报文也可以显示在简明表格中。

示波器——串行触发和解码
打开灯箱

在波形和结果表格中显示解码协议细节

支持针对不同事件和各种错误条件的强大触发功能

借助特定于协议的触发,用户能够可靠地隔离协议事件和错误。罗德与施瓦茨示波器具有高捕获率,非常适合快速查找错误,以便针对特定于协议的触发结果进行解码。示波器可针对地址、数据和协议错误等特定协议内容进行基于硬件的触发。

示波器——串行触发和解码
打开灯箱

提供全面的协议类型可选以进行触发,以便专注于采集感兴趣的细节信息

强大的搜索和导航功能

全面的搜索功能让长信号序列的分析更加简单。用户可以根据不同的标准搜索波形,例如信号故障或协议内容。所有检测到的事件均显示在表格中,并带有时间戳。用户可以在缩放窗口中查看单个事件,并轻松浏览不同事件。
示波器——串行触发和解码
打开灯箱

在长采集中搜索协议细节

选件名称
串行标准
解码表
触发
搜索
基本单元
R&S®RTP-K72

订单号码 1337.8827.02

串行标准
PCI Express 1.1./2.0
解码表
触发
搜索
基本单元
R&S®RTP
R&S®RTO-K72

订单号码 1326.3741.02

串行标准
PCI Express 1.1./2.0
解码表
触发
搜索
基本单元
R&S®RTO2000
