车载网络和 ECU 测试

车载以太网和其他总线系统

通常，一辆汽车内部会有 100 多个电子控制单元 (ECU) 用以控制各种系统，包括刹车、变速器、发动机、空调、转向、摄像头、雷达、声传感器以及非蜂窝和蜂窝无线通信。

ECU 之间通过汽车总线进行通信，包括控制器局域网 (CAN)、媒体导向系统传输 (MOST)、局域互连网络 (LIN) 和 FlexRay 总线。

汽车电子原始设备制造商和一级供应商正在从混合多种不同总线类型转为采用更为统一的总线类型，确保数据吞吐量更高、延迟更低、重量更轻，从而减少复杂性并增加成本效益。

罗德与施瓦茨车载以太网测试解决方案的特点：

针对 CAN、CAN-FD、LIN、FlexRay、CXPI、SENT、100BASE-T1 和 1000BASE-T1 的触发和解码功能
根据 802.3cg、802.3bw、802.3bp、802.3ch 等标准的车载以太网一致性测试（10BASE-T1S、100BASE-T1、1000BASE-T1、2.5/5/10GBASE-T1）
根据 OPEN 联盟 TC9 规范的通道和连接器测试（100BASE-T1、1000BASE-T1、2.5/5/10GBASE-T1）
电磁干扰 (EMI) 调试、车载网络 (IVN) 信号和电源完整性验证与分析
