R&S®Cloud4Testing: Transient analysis application package

适用于频率捷变雷达系统的云测试解决方案

R&S®Cloud4Testing: Transient analysis application package
打开灯箱
R&S®Cloud4Testing:瞬态分析应用包,屏幕截图

主要特点

  • 非常适用于瞬态测量
  • 包含跳频序列分析功能
  • 测量线性调频信号或调频连续波信号
  • 提供灵活的订阅模式

应对瞬态分析挑战,需要精益解决方案

基于云的软件可用于测量频率捷变信号的特性

借助 R&S®Cloud4Testing,用户可以快速简单地使用罗德与施瓦茨的瞬态分析测试仪器,不必投入大量成本。用户可以随时根据需要轻松测量、分析和处理各种射频数据。

此瞬态分析应用包适用于 R&S®Cloud4Testing,并可用于 R&S®VSE-K60 瞬态分析选件,非常适合需要对频率捷变信号进行特性分析的雷达系统制造商和开发人员,包括分析跳频序列 (R&S®VSE-K60H) 和线性调频信号或调频连续波信号 (R&S®VSE-K60C)。

特性和优点

线性调频分析

R&S®VSE-K60C 选件可显示频率响应,并计算与理想线性相位的偏差,即使对于汽车电子雷达中的非脉冲调频连续波雷达信号也是如此。
测量参数:
频率偏差、线性调频起始、线性调频长度、调频斜率、线性调频状态偏差、相位偏差、功率、电源纹波

打开灯箱

跳频信号

R&S®VSE-K60H 自动分析汽车电子以及航空航天和国防应用中使用的快速跳频脉冲信号的跳频序列。
测量参数:
驻留时间、稳定时间、切换时间、频率偏差、功率、相位偏差、电源纹波

深度分析

瀑布图和瀑布图部分、表格显示、频率、频率误差、相位和幅度与时间的关系、FFT 频谱
平移和缩放功能可在瀑布图、频谱和时域迹线显示中使用触控手势选择分析区域
所有参数的趋势和直方图
跳频/线性调频统计数据:标准差、平均值、最大值、最小值
用户自定义的测量参数

可用型號

可用型號
型号
有效期

Transient Analysis Free Trial

有效期
30 天

Transient Analysis

有效期
12 个月
