射频和微波功率计

兼具可靠性和准确性

射频和微波功率计

探索罗德与施瓦茨的射频功率计、微波功率计和探头产品组合,实现一流的测量精度和速度

我们的射频和微波功率探头确保测量精确、可靠。这些产品具有出色的测量精度和速度,操作简单,热量、二极管和 OTA 核心测量元件采用领先技术,符合国家级标准并保障可追溯性。这使罗德与施瓦茨成为准确进行功率测量的首选。从通用、定向和微波功率探头,到适合太空环境的功率探头或选频功率探头,罗德与施瓦茨能够满足您的各种应用要求。

射频和微波功率探头
产品名称
探头类型
频率范围
电平范围
连接器类型
探头类型
三通道二极管功率探头
频率范围
10 MHz - 90 GHz
电平范围
-70 dBm - +45 dBm
连接器类型
USB/LAN
探头类型
Pulse
频率范围
50 MHz - 50 GHz
电平范围
-60 dBm - +20 dBm
连接器类型
USB
探头类型
平均功率探头
频率范围
8 kHz - 18 GHz
电平范围
-70 dBm - +23 dBm
连接器类型
USB/LAN
探头类型
热功率探头
频率范围
DC - 170 GHz
电平范围
-35 dBm - +20 dBm
连接头类型
USB/LAN
探头类型
选频功率探头
频率范围
50 MHz - 6 GHz
电平范围
-130 dBm - +20 dBm
连接头类型
USB/LAN
探头类型
OTA
频率范围
18 GHz - 90 GHz
电平范围
-76 dBm - -19 dBm
连接器类型
USB/LAN
探头类型
双通道二极管功率探头
频率范围
10 MHz - 18 GHz
电平范围
-60 dBm - +20 dBm
连接器类型
USB (COM)
功率计基本单元
产品名称
基本单元类型
最大通道
互联性能
测量
基本单元类型
功率计
最大通道
4
互联性能
USB/LAN/GPIB
测量
所有
基本单元类型
反射计
最大通道
1
互联性能
USB/LAN/GPIB
测量
定向(前向/反向)
校准解决方案
产品名称
频率范围
应用
PTB 可追溯
频率范围
DC - 67 GHz
应用
功率探头校准
PTB 可追溯
    03 比较产品
    选择至少2个产品
